ENGI 3016-SDE: Engineering Mechanics (Summer 2024) - Final Exam
Date: July \( 12^{\text {th }}, 2024 \)
Question (1)
(15 Marks)
The bracket shown in the figure is supported by a ball at \( A \), a cable at \( B \) and a ball-andsocketat \( C \). If the bracket is subjected to a vertical load \( (\mathrm{P}=100 \mathrm{~N}) \), as shown in the figure, determine all support reactions. Ignore the bracket weight.
Notes: All dimerisions are in (mm).
