Given:
- Resistance between a and b = 10 ohms
- Resistance between b and c = 10 ohms
Since these two resistances are in series, their equivalent resistance is:
\[ R_1 = 10 \Omega + 10 \Omega = 20 \Omega \]
Now, the 20 ohm resistor is in parallel with the 10 ohm
Show more…
