Question

For the circuit shown in the Figure, if V1=13 V and V2=23 V, the value of v(t), where t is the circuit time constant, is: i + V2 V1 + 2 H t=0 + 2? 3 ? V 6? - Oa. 13.4 V Ob. 9.4 V Oc. 7.4 V Od. 11.4 V

          For the circuit shown in the Figure, if V1=13 V and
V2=23 V, the value of v(t), where t is the circuit time
constant, is:
i
+
V2
V1
+
2 H
t=0
+
2?
3 ?
V
6?
-
Oa. 13.4 V
Ob. 9.4 V
Oc. 7.4 V
Od. 11.4 V

Added by Roberto J.

JEE Physics

StemEZ 1st Edition

Chapter 12

Instant Answer

Solved by Expert Vishal Gupta

Step 1

We can see that the 2H inductor and the 3Ω resistor are in series, so their equivalent resistance is 2 + 3 = 5Ω. Show more…

Show all steps

Thanks for your feedback!

For the circuit shown in the Figure, if V1 = 13V and V2 = 23V, the value of v(t) where T is the circuit time constant, is: V2 V1 2H t = 0 20 3 6 a. 13.4V b. 9.4V c. 7.4V d. 11.4V
