For the plane truss structure shown in Figure P3-20, determine the displacement of node 2 using the stiffness method. Also determine the stress in element 1. Let A = 5 in2, E= 1 x 106 psi, and L = 100 in. 1 L 10 kip 2 L ② 1 45° 45° 3 Figure P3-20 4 3 2 L 30° 30° 141 lb Figure P3-21 45°
