For the sinusoidally modulated DSB-SC waveform shown in Fig: below: a- Find the modulation index. b- Sketch a line spectrum. c- Calculate the ratio of average power in the sidebands to that in the carrier. d- Determine the amplitude of the additional carrier, which must be added to obtain a modulation index of 100%.

          For the sinusoidally modulated DSB-SC waveform shown in Fig: below:
a- Find the modulation index.
b- Sketch a line spectrum.
c- Calculate the ratio of average power in the sidebands to that in the carrier.
d- Determine the amplitude of the additional carrier, which must be added to obtain a modulation index of 100%.
