Given:
rod AB has a weight of 25 kN/m and a length of 3 m and is
supported at A with a vertical rod and collar. You can assume
the weight is concentrated at the center of the rod.
Find:
The tension in cable BC to hold the rod in the position shown. A
correct free body diagram is required.
X
A
3 m
21.7
60°
C
B
