Question 2. (125 marks) (a) An overhead trolley conveyor is configured as a continuous closed loop. The delivery loop has a length of 120 m and the return loop = 80 m. All parts loaded at the load station are unloaded at the unload station. Each hook on the conveyor can hold one part and the hooks are separated by 4 m. Conveyor speed = 1.25 m/s. Determine: (i) maximum number of parts in the conveyor system, (ii) parts flow rate; and (iii) maximum loading and unloading times that are compatible with the operation of the conveyor system? (b) Compute the cycle time and production rate for a single-machine robotic cell for an 8- hour shift if the system availability is 90%. Also determine the percent utilization of machine and robot. On average, the machine takes 30 s to process part. The other robot operation times as follows: Robot picks up a part from the conveyor 3.0 s Robot moves the part to the machine 1.3 s Robot loads the part onto the machine 1.0 s Robot unloads the part to the machine 0.7 s
Added by Yolanda L.
Close
Step 1
### Part (a) #### Show more…
Show all steps
Your feedback will help us improve your experience
Anand Jangid and 56 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Madhur L.
A production system receives products from the warehouse every UNIF(5,7) minutes. When parts arrive, they are processed by a 1st machine, processing time is TRIA(3,4,8) minutes. The parts are then separated to produce two different types of products (type A and Type B). 50% of the parts are being labeled type A and are sent to a second processing machine, processing time follows 5+expo(1.8) after they finish, they go to the warehouse. The other 50%, labeled Type B, are send directly to the finished goods warehouse after being processed from the 1st machine. Run the system for 40 hours, do 10 replications and answer the following: A. The average number of parts of type A produced by the system is about 200. B. The average total time is 74 min for any product type. C. The utilization of the first machine is about 83% D. The average waiting time at machine 1 is about 16 seconds. E. The average WIP is 1.53 product.
Shaiju T.
A carousel storage system is to be designed to serve a mechanical assembly plant. The specifications for the system are that it must have a total of 400 storage bins and a throughput of at least 125 storage and retrieval transactions per hour. Two alternative configurations are being considered: (1) a one-carousel system and (2) a two-carousel system. In either case, the width of the carousel is to be 4.0 ft and the spacing between carriers is 2.5 ft. One picker-operator will be required for the one-carousel system and two picker-operators will be required for the two-carousel system. In either system, vc = 100 ft/min. For the convenience of the picker-operator, the height of the carousel will be limited to 5 bins. The standard time for a pick and deposit operation at the load/unload station is 0.4 min if one part is picked or stored per bin and 0.6 min if more than one part is picked or stored. Assume that 50% of the transactions will involve more than one component. Determine (a) the required length of the one-carousel system and (b) the corresponding throughput rate; (c) the required length of the two-carousel system and (d) the corresponding throughput rate. (e) Which system better satisfies the design specifications?
