Question

Here is a simplified diagram of a RF front end (power and control signals are not shown). 1. What kind of a system is it? What are the RF measurements you would use to characterize it and compare it with other similar systems? 2. What bandwidth could you obtain with it (consider bandwidth of the components only). What range resolution would a radar operating at this bandwidth have? 3. How much data (after downconversion) will the system generate at the above bandwidth (bits/s)? QPA2609 TGP2109-SM QPA2609 TGP2109-SM RF OUTO QPA2609 TGP2109-SM QPA2609 TGP2109-SM ANT1 TGA2704-SM TGS2352-2-SM ANT2 TGA2704-SM TGS2352-2-SM ANT3 TGA2704-SM TGS2352-2-SM ANT4 TGA2704-SM TGS2352-2-SM TGP2109-SM TGP2109-SM ORF IN TGP2109-SM TGP2109-SM

          Here is a simplified diagram of a RF front end (power and control signals are not shown).
1. What kind of a system is it? What are the RF measurements you would use to characterize it and
compare it with other similar systems?
2. What bandwidth could you obtain with it (consider bandwidth of the components only). What range
resolution would a radar operating at this bandwidth have?
3. How much data (after downconversion) will the system generate at the above bandwidth (bits/s)?
