Hi, I can't get the correct draft number from following question. I get 0.5195m. Weight of bouy + weight of mooring lines = bouyancy of bouy... Am I wrong? A CALM buoy is moored in 30m water depth using a 6 line configuration. The CALM buoy is cylindrical with a diameter of 5m and mass 5 tonnes. Mooring chain of submerged weight 300 N/m is used throughout. The chain attachment points are on the outer edge of the CALM buoy and at its base. The tension force is measured at the attachments and is 15kN in each chain. a) What is the draft (i.e. distance from the base to the waterline) of the CALM buoy in calm conditions? (answer = 0.6635m).
Added by Liam K.
Step 1
First, we need to find the volume of the submerged part of the buoy. To do this, we'll use the buoyancy formula: Buoyancy = Weight of buoy + Weight of mooring lines Show more…
Show all steps
Your feedback will help us improve your experience
Frank Deng and 57 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Rather than lifting the buoy of Problem 35 and Figure 20 out of the water, suppose that we attempt to push it down until its top is even with the water level. Assume that $h=8,$ that the top is originally 2 feet above water level, and that the buoy weighs 300 pounds. How much work is required? Hint: You do not need to know $a$ (the radius at water level), but it is helpful to know that $\delta\left(\frac{1}{3} \pi a^{2}\right)(8)=300 .$ Archimedes' Principle implies that the force needed to hold the buoy $z$ feet $(0 \leq z \leq 2)$ below floating position is equal to the weight of the additional water displaced.
Applications of the Integral
Work and Fluid Force
Arehimedes' Principle A spherical buoy has a radius of 1 $\mathrm{m}$ and a density one-fourth that of seawater. By Archimedes' Principle, the weight of the displaced water will equal the weight of the buoy. . Let $x=$ the depth to which the buoy sinks. . Let $d=$ the density of seawater. $\cdot$ Let $r=$ the radius of the circle formed where buoy, air, and water meet. See the figure below. Notice in the figure that $r^{2}=1-(1-x)^{2}=2 x-x^{2},$ and recall from geometry that the volume of submerged spherical cap is $$V=\frac{\pi x}{6} \cdot\left(3 r^{2}+x^{2}\right)$$ (a) Verify that the volume of the buoy is 4$\pi / 3$ . (b) Use your result from (a) to establish the weight of the buoy as $\pi d / 3 .$ (e) Prove the weight of the displaced water is $\pi d \cdot x\left(3 r^{2}+x^{2}\right) / 6 .$ (d) Approximate the depth to which the buoy will sink.
Polynomial, Power, and Rational Functions
Real Zeros of Polynomial Functions
Oceanography As shown in Figure $13-29$, a large buoy used to support an oceanographic research instrument is made of a cylindrical, hollow iron tank. The tank is $2.1 \mathrm{m}$ in height and $0.33 \mathrm{m}$ in diameter. The total mass of the buoy and the research instrument is about 120 kg. The buoy must float so that one end is above the water to support a radio transmitter. Assuming that the mass of the buoy is evenly distributed, how much of the buoy will be above the waterline when it is floating? (FIGURE CANNOT COPY)
