          HOMEWORK #4B: STRAIN & LOAD SENSORS (Individual Homework) - TORQUE CELL

The figure below shows a torque cell designed to measure the torque T applied to a solid circular shaft of diameter D. The torque cell is made of four strain gauges mounted to form a full-bridge Wheatstone circuit. It is known that the strains and torque are related by: 16T1 + v21 = -82 = 83 = -84 TD E, where Îµ (i=1,2,3,4) are the strains in the four gauges, and E and v are the Young's modulus and Poisson's ratio of the shaft, respectively. Determine the instrument sensitivity S between the output voltage Eo and the applied torque T.

Gage 1
Gage 3
Gages 3 and 4 on opposite side
Gage 4
Gage 2
+
1
2
Eo
Right 3
4
-Ei+
