00:01
Different types of line that are used in technical drawing, engineering drawing.
00:09
The first one that we're talking about heavy solid line to frame into, to framing the drawing.
00:20
Okay? they're actually referring to t continuous line.
00:30
Okay? they are used for half lines.
00:35
So let's let's just draw it, you are tick, sorry, tick and continuous, tick continuous line, okay? and continuous.
01:08
So the thickness is equal, my, my drawing, tick and continuous of equal thickness, all true, uniform, all right.
01:37
So that's, tick and continuous, okay? so you call these heavy solid line.
02:08
Okay, every solid line.
02:10
I can say thick continuous line.
02:23
Continuous line.
02:40
So you use it for, especially for outline.
02:43
And as we said, they have to frame in drawing.
02:48
Then we also have what we call the other one.
02:53
They said, medium line line used to show edges and contour not visible you can also call this short dash line something like this equal spacing don't mind my own spacing thickness is not as it's medium thickness okay medium thickness so you call these are short medium line solid line same thing i said tic continuance i've said medium line.
04:06
Okay? you can also call it short dash line.
04:23
Now it is used for hidden details.
04:26
Let's say you have a block and there's a hole in the block...
