Impulse and Momentum Activity 11: Impulse - Momentum Truth Table Adapted from The Physics Classroom Quick Quiz https://www.physicsclassroom.com/class/momentum/Lesson-1/Momentum-and-Impulse-Connection Directions: Fill in the table below by applying the Impulse-Momentum Theorem and answer the questions that follow. \begin{tabular}{|c|c|c|c|c|c|} \hline \begin{tabular}{c} Force \\ (N) \end{tabular} & \begin{tabular}{c} Time \\ \( (\mathbf{s}) \) \end{tabular} & \begin{tabular}{c} Impulse \\ \( \mathbf{( N \cdot s )} \) \end{tabular} & \begin{tabular}{c} Momentum \\ Change \\ \( (\mathbf{k g} \cdot \mathbf{m} / \mathbf{s}) \) \end{tabular} & \begin{tabular}{c} Mass \\ \( (\mathbf{k g}) \) \end{tabular} & \begin{tabular}{c} Velocity \\ Change \\ \( (\mathbf{m} / \mathbf{s}) \) \end{tabular} \\ \hline & 0.05 & & & 10 & -5 \\ \hline & 0.5 & -50 & & 10 & \\ \hline-5000 & 0.05 & & -250 & 50 & \\ \hline-250 & & & -250 & & -10 \\ \hline \end{tabular}
Added by Galaxyslayer Z.
Close
Step 1
The Impulse-Momentum Theorem states that the change in momentum of an object equals the impulse applied to it. In other words, Impulse = Force * Time = Change in Momentum. Show moreβ¦
Show all steps
Your feedback will help us improve your experience
Lien Le and 92 other Physics 103 educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Mass of cart (kg) Final Velocity vf (m/s) Initial Velocity vi (m/s) Velocity Change Ξv (m/s) Momentum Change Ξp (kg m/s) Impulse I (N s) % difference between Impulse and Change in momentum 0.494 0.452 -0.535 0.4984 0.996 0.558 -0.607 1.133 1.498 0.557 -0.623 1.696 Calculate the change in velocities and record in the data table. From the mass of the cart and change in velocity, determine the change in momentum as a result of the impulse. Show all work and calculations.
Madhur L.
What impulse is required to act on a 16 kg object initially moving at 12 m/s in order to change the object's momentum by 72 kgΒ·m/s? Group of answer choices: 72 NΒ·s 192 NΒ·s 4.5 NΒ·s 24 NΒ·s 8.1 NΒ·s 2.4 NΒ·s 0.4 NΒ·s 6.0 NΒ·s If Julianna (45 kg) is riding her 20 kg bike at a constant velocity of 6.32 m/s to work, what is her momentum and impulse? Group of answer choices: Her momentum is 284 kgΒ·m/s and her impulse is 0 NΒ·s Her momentum is 0 kgΒ·m/s and her impulse is 284 NΒ·s Her momentum is 284 kgΒ·m/s and her impulse is 284 NΒ·s Her momentum is 0 kgΒ·m/s and her impulse is 411 NΒ·s Her momentum is 411 kgΒ·m/s and her impulse is 411 NΒ·s Her momentum is 411 kgΒ·m/s and her impulse is 0 NΒ·s Mr. Carbone is playing in his old man's hockey league. He takes his legendary slapshot by hitting the puck with a 42.8 N force. The puck leaves his stick after 0.21 s. What is the impulse experienced by the puck? Group of answer choices: 138 NΒ·s 43 NΒ·s 216 NΒ·s 0.0 NΒ·s 204 NΒ·s 21 NΒ·s 9 NΒ·s 114 NΒ·s
Adam M.
Mathematically express the impulse-change in momentum relationship.
