In the figure below, two 1½" diameter bolts are used to fasten the seat angle to the column. If the load on the beam is 9k, determine the average shear stress in the bolts. WIDE FLANGE COLUMN WIDE FLANGE BEAM SEAT ANGLE P = 9 kips
Added by Marina M.
Close
Step 1
Since there are two bolts, the total force on the bolts is 9 kips * 2 = 18 kips. Show more…
Show all steps
Your feedback will help us improve your experience
Sri K and 61 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
An angle bracket having a thickness $t=0.75$ in. is attached to the flange of a column by two $5 / 8$ -inch diameter bolts (see figure). A uniformly distributed load from a floor joist acts on the top face of the bracket with a pressure $p=275$ psi. The top face of the bracket has a length $L=8$ in. and width $b=3.0$ in. Determine the average bearing pressure $\sigma_{b}$ between the angle bracket and the bolts and the average shear stress $\tau_{\text {aver }}$ in the bolts. Disregard friction between the bracket and the column.
Sri K.
Four $\mathrm{L} 102 \times 102 \times 9.5$ steel angle shapes and a $12 \times 400-\mathrm{mm}$ plate are bolted together to form a beam with the cross section shown. The bolts are of 22 -mm diameter and are spaced longitudinally every $120 \mathrm{mm} .$ Knowing that the beam is subjected to a vertical shear of $240 \mathrm{kN}$, determine the average shearing stress in each bolt.
Madhur L.
Four $L 102 \times 102 \times 9.5$ steel angle shapes and a $12 \times 400$ -mm plate are bolted together to form a beam with the cross section shown. The bolts are of 22 -mm diameter and are spaced longitudinally every $120 \mathrm{mm} .$ Knowing that the beam is subjected to a vertical shear of $240 \mathrm{kN},$ determine the average shearing stress in each bolt.
