Question

(j) Calculate: (i) the carrier concentration, and (ii) the proportion of current carried by holes in an intrinsic Ge crystal at 300 K which has a conductivity of 2.0 -1m-1. Assume n  0.38 and p  0.18 m2V-1s-1.

Name: j calculate i the carrier concentration and ii the proportion of current carried by holes in an intrinsic ge crystal at 300 k which has a conductivity of 20 1m 1 assume n 038 and p 018 m2v 1 72615
Uploaded: 2021-07-13T19:00:10-08:00
Duration: 3 min 15 s
Channel: Dr. Rajveer Singh
Description: j calculate i the carrier concentration and ii the proportion of current carried by holes in an intrinsic ge crystal at 300 k which has a conductivity of 20 1m 1 assume n 038 and p 018 m2v 1 72615

          (j) Calculate: (i) the carrier concentration, and (ii) the proportion of current carried by holes in an intrinsic Ge crystal at 300 K which has a conductivity of 2.0 -1m-1. Assume n  0.38 and p  0.18 m2V-1s-1.

Added by Rebecca R.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Dr. Rajveer Singh

07/13/2021

Step 1

0 Ω⁻¹ m⁻¹, q = 1.6 × 10⁻¹⁹ C, μn = 0.38 m² V⁻¹ s⁻¹, μp = 0.18 m² V⁻¹ s⁻¹. μn + μp = 0.56 m² V⁻¹ s⁻¹ ni = σ / [q (μn + μp)] = 2.0 / [1.6×10⁻¹⁹ × 0.56] ≈ 2.2 × 10¹⁹ m⁻³. Show more…

Show all steps
