3. Let the energy stored "in the capacitor" be U. Show that U is given by the expression: U = 1/2 Q^2/C [Hint: The power P in the capacitor is given by P = dU/dt = IV where I = dQ/dt. This is a simple exercise on integration.] 4. Calculate the energy stored in the capacitor network in the figure below when the capacitors are fully charged and when the capacitances are C1=12.0?F, C2=2.0?F , and C3=4.0?F , respectively.

          3. Let the energy stored "in the capacitor" be U. Show that U is given by the expression: U = 1/2 Q^2/C

[Hint: The power P in the capacitor is given by P = dU/dt = IV where I = dQ/dt. This is a simple exercise on integration.]

4. Calculate the energy stored in the capacitor network in the figure below when the capacitors are fully charged and when the capacitances are C1=12.0?F, C2=2.0?F , and C3=4.0?F , respectively.

Show more…

3. Let the energy stored "in the capacitor" be U. Show that U is given by the expression: U = 1/2 Q^2/C

[Hint: The power P in the capacitor is given by P = dU/dt = IV where I = dQ/dt. This is a simple exercise on integration.]

4. Calculate the energy stored in the capacitor network in the figure below when the capacitors are fully charged and when the capacitances are C1=12.0?F, C2=2.0?F , and C3=4.0?F , respectively.

Added by Ines G.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Nirmal P

02/23/2022

Step 1

We are given the power P in a capacitor as P = IV, where I = dQ/dt. We need to show that the energy stored in the capacitor, U, is given by the expression U = Q^2/2C. Then, we need to calculate the energy stored in a network of capacitors with given capacitances Show more…

Show all steps

lock

Thanks for your feedback!

Let the energy stored "in the capacitor" be U. Show that U is given by the expression: U = 1/2 Q^2/C [Hint: The power P in the capacitor is given by P = dU/dt = IV where I = dQ/dt. This is a simple exercise on integration.] 4. Calculate the energy stored in the capacitor network in the figure below when the capacitors are fully charged and when the capacitances are C1=12.0μF,C2=2.0μF , and C3=4.0μF , respectively.

Play audio

Feedback

Powered by NumerAI

Nirmal P and 91 other subject Physics 101 Mechanics educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Recommended Videos

Recommended Textbooks

Transcript

00:01 In this question we will calculate the energy stored in a capacitor can be written as u is equal to q squared divided by 2c.

00:08 In part b we will calculate energy stored in a capacitor network.

00:13 So first of all we will solve the part a.

00:16 In part a we can write power p is equal to v multiplied with the i here v is the voltage, i is the flow of current.

00:27 So we can write power p is nothing but an energy.

00:30 Energy flow.

00:31 So del u divided by del t, here u is the energy.

00:36 So we can write del u divided by del t is equal to v multiplied with the del q divided by del t.

00:44 Here i is can be written as del q divided by del t if with del t cancels each other so we can write del u is equal to v multiplied with the del q.

00:56 In the case of capacitor we can write charge q is equal to c multiplied with the v from these values where voltage v can be written as q divided by c if we plug in the value of voltage v is equal to q divided by c we will get del u is equal to q divided by c del q if we integrate the both the terms u from del u from 0 to u del u can be written as if we integrate charge from 0 to q q ddl q divided by c from this value we will get u is equal to energy stored in capacitor is equal to q squared divided by 2c so this is the formula this is the formula that we have to prove that energy stored in a capacitor u is equal to q squared divided by 2c.

01:59 So here we have completed the first part and let we solve the second part.

02:05 In the second part we have given a network of three capacitors, c1, c2 and c3.

02:13 Value of c1, c2 and c3 is given in the question...
