2. A sinusoidal force function w with maximum load of 600 N/m and minimum load of 0 is applied to a carbon steel bar as shown in figure for Problem 1. Choose material to yield factor of safety of 5 for ambient temperature function with reliability of 50% and surface correction factor of 1. (15 points) y Cross section=2 cm x 5 cm B l=1 m

          2.
A sinusoidal force function w with maximum load of 600 N/m and minimum load of 0 is applied to a
carbon steel bar as shown in figure for Problem 1. Choose material to yield factor of safety of 5 for
ambient temperature function with reliability of 50% and surface correction factor of 1. (15 points)
