Main Sequence - Explain Each Step
Network 1: Push start button = green LED goes on
Comment
%0.0 *START PB*
%Q0.1 GREEN LED*
Network 2: Push start button, motor comes on. Press reset, it turns off
Comment
%0.0 *START PB*
%0.2 RESET PB* V
%Q0.0 MOTOR*
%Q0.0 MOTOR*
Network 3: Two ways to turn on - the start PB and key, and the foot pedal. Latched with two ways to turn off with the reset PB or optical sensor
%0.6 OPTICAL SENSOR*
%0.0 *START PB*
%0.3
%0.2 RESET PB
%Q0.4 "BUZZER*
*KEY SWITCH*
%1.0
"FOOT PEDAL*
%Q0.4 BUZZER* HH
