Match the way you connected with your effect. A B C D 1. ...

Match the way you connected with your effect. A B C D 1. ____ increases the current of the cell or battery, a power off does not affect others. 2. ____ same voltage, but can produce more current. 3. ____ increase the voltage. 4. ____ resistance increases, one shutdown turns off all OPTIONS: B A C D

Transcript

00:01 In this example, we have four diagrams.

00:03 The first diagram is we have two batteries connected in series.

00:08 So we have positive, negative, positive, negative.

00:12 So the batteries are connected as this.

00:16 So let's just say this has some voltage.

00:18 We're not worried about the values of the voltage.

00:22 And then in diagram b, we have two batteries connected in parallel.

00:26 So that means we're going to have positive to positive and negative to negative.

00:34 So these are my two batteries in parallel, part of a little circuit here.

00:42 Our third diagram is going to be two resistors in series.

00:47 So we have r1 connected to r2, 1, r2.

00:54 So this will be battery 1, battery 2, battery 1, battery 2.

00:58 And then in our third diagram, we have two resistors connected in parallel.

01:04 So we have r1, r2.

01:08 Then we're given four different effects.

01:11 And we want to match each effect to each diagram.

01:14 So my first effect is this setup will increase current out of the cell or battery, but a power off does not affect others.

01:24 So i increases power off.

01:30 I guess i'll say is independent.

01:35 And this will be for the case of two resistors in parallel.

01:41 So for case d, when one of these resistors breaks, the current is still able to go through path 1.

01:48 Let's say resistor 2 fails...
