Example 7-1 What is the voltage between the collector and ground in the Multisim Fig. 7-3? Between the collector and the emitter? And show that you get the same collector voltage as the calculated result using Multisim also. IIII Multisim Figure 73 Meter Values. VBB 5 V Vcc 15V XMM1 RC 2?? Q1 2N3904 + RE 1?? XMM2

          Example 7-1
What is the voltage between the collector and ground in the Multisim Fig. 7-3?
Between the collector and the emitter? And show that you get the same collector voltage as the
calculated result using Multisim also.
IIII Multisim Figure 73 Meter Values.
VBB
5 V
Vcc
15V
XMM1
RC
2??
Q1
2N3904
+
RE
1??
XMM2

Example 7-1
What is the voltage between the collector and ground in the Multisim Fig. 7-3?
Between the collector and the emitter? And show that you get the same collector voltage as the
calculated result using Multisim also.
IIII Multisim Figure 73 Meter Values.
VBB
5 V
Vcc
15V
XMM1
RC
2??
Q1
2N3904
+
RE
1??
XMM2

Added by Amanda D.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Penny Riley

Step 1

In the given circuit, the collector is connected to the positive terminal of the power supply (Vcc = 15V) and the ground is connected to the negative terminal of the power supply. Therefore, the voltage between the collector and ground is equal to the power supply Show more…

Show all steps

Thanks for your feedback!

Example 7-1: Multisim Question What is the voltage between the collector and ground in the Multisim Fig. 7-3? Between the collector and the emitter? And show that you get the same collector voltage as the calculated result using Multisim also. Multisim Figure 7-3: Meter Values Vcc = 15V XMM1 RC = 2kÎ© XMM2 2N3904 VBB = 5V RE = 1kÎ©
