Q5(a) Figure Q5(a) shows a basic series voltage regulator circuit.

(i)

(ii)

VIN

RREF

Q1

U1

R1 = 20 kΩ

D1

R2 > 30 kΩ

Figure Q5(a)

VOUT

Calculate the output voltage, VOUT if VIN = 50 V and voltage drop across

D1 = 6.2 V.

(3 marks)

Illustrate a circuit diagram for overload protection between transistor (Q1)

and the load.

(4 marks)

(iii)

(b)

Based on the answer in Q5(a)(ii), calculate the overload current IL(max).

Figure Q5(b) shows a voltage regulator.

(3 marks)

+35 V

C1

LM 317

+Vout

↑

VREO 220 Ω

R1

C3

IADJ

R2'

R2

C2

5 kΩ

(i)

Figure Q5(b)

Determine the maximum and minimum output voltage for the voltage

regulator in Figure Q5(b), if IADJ = 25 μ A and VREO = 0.9 V.

(7 marks)

(ii) Determine the output voltage of the regulator if R2 is set to 4 kkk.

(3 marks)
