O4 (15 POINTS) Acetylene gas \( \left(\mathrm{C}_{2} \mathrm{H}_{2}\right) \) is produced from the dehydrogenation of methane \( \left(\mathrm{CH}_{4}\right) \) in a continuous reactor. An undesired side reaction is the decomp osition of acetylene to carbon. \[ \begin{array}{l} 2 \mathrm{CH}_{4}(\mathrm{~g}) \longrightarrow \mathrm{C}_{2} \mathrm{H}_{2}(\mathrm{~g})+3 \mathrm{H}_{2}(\mathrm{~g}) \\ \mathrm{C}_{2} \mathrm{H}_{2}(\mathrm{~g}) \longrightarrow \longrightarrow \mathrm{C}(\mathrm{s})+\mathrm{H}_{2}(\mathrm{~g}) \end{array} \] Methane is fed to the reactor at \( 1500^{\circ} \mathrm{C} \) at a rate of \( \mathbf{1 0 0} \mathrm{mol} / \mathrm{s} \). Heat is transferred to the reactor at a rate of \( 9750 \mathrm{~kW} \). The product temperature is at \( 1500^{\circ} \mathrm{C} \) and the fractional conversion of methane is \( 60 \% \). Determine the product components flow rates and the yield of acetylene ( \( \mathrm{mol} \mathrm{C}_{2} \mathrm{H}_{2} \) produced \( / \mathrm{mol} \mathrm{CH} 4 \) consumed). Data: Specific heat capacities for: \[ \begin{array}{ll} \text { Data: Specific heat capacities for: } & C_{2} \mathrm{H}_{2}(g): C p=0.052 \frac{\mathrm{kJ}}{\mathrm{mol} . \mathrm{C}} \\ \mathrm{CH}_{4}(g): C p=0.079 \frac{\mathrm{kJ}}{\mathrm{mol.C}} & \mathrm{C}(\mathrm{s}): C p=0.022 \frac{\mathrm{kj}}{\mathrm{mol} . \mathrm{C}} \\ \mathrm{H}_{2}(g): C p=0.031 \frac{\mathrm{kJ}}{\mathrm{mol.C}} & \end{array} \]
Added by George R.
Close
Step 1
The fractional conversion of methane is 60%, and the feed rate of methane is 100 mol/s. Therefore, the moles of methane converted per second is: \[ \text{Moles of CH₄ converted} = 100 \text{ mol/s} \times 0.60 = 60 \text{ mol/s} \] Show more…
Show all steps
