Fluid coming out of a pipe has a volumetric flow rate of ? = 7.31×10? m³/s (I'm only using this variable name for convenience in your partial credit work). At the outlet, the diameter of the pipe is d? = 1.00 cm. Further back from the outlet but at the same height is a different diameter pipe where d? = 5.05 cm. Above this outlet a distance h is another pipe of diameter d? = 7.81 cm. This is indicated in the picture here. d?, P? h d?, P? d?, P? We also know P? – P? = P?? = -5.69 kPa and P? – P? = P?? = -53.7 kPa. a. (Q7 ans 2 pts, Q8 work 5 pts) What is the velocity of the fluid at point 3? b. (Q9, 7 pts) What is the velocity of the fluid at point 2? c. (Q10, 7 pts) What is the density of the fluid? (As a hint, you only need points 2 and 3 for this). d. (Q11, 7 pts) What is the height difference between points 1 and 2, called h in this picture? To continue, please give the fluid velocity at point 3 (part a) in units of m/s.

          Fluid coming out of a pipe has a volumetric flow rate of ? = 7.31&#215;10? m&#179;/s (I'm only using this
variable name for convenience in your partial credit work). At the outlet, the diameter of the pipe is
d? = 1.00 cm. Further back from the outlet but at the same height is a different diameter pipe where
d? = 5.05 cm. Above this outlet a distance h is another pipe of diameter d? = 7.81 cm. This is
indicated in the picture here.
d?, P?
h
d?, P? d?, P?
We also know P? – P? = P?? = -5.69 kPa and P? – P? = P?? = -53.7 kPa.
a. (Q7 ans 2 pts, Q8 work 5 pts) What is the velocity of the fluid at point 3?
b. (Q9, 7 pts) What is the velocity of the fluid at point 2?
c. (Q10, 7 pts) What is the density of the fluid? (As a hint, you only need points 2 and 3 for this).
d. (Q11, 7 pts) What is the height difference between points 1 and 2, called h in this picture?
To continue, please give the fluid velocity at point 3 (part a) in units of m/s.

Show more…

Fluid coming out of a pipe has a volumetric flow rate of ? = 7.31 #215;10? m #179;/s (I'm only using this
variable name for convenience in your partial credit work). At the outlet, the diameter of the pipe is
d? = 1.00 cm. Further back from the outlet but at the same height is a different diameter pipe where
d? = 5.05 cm. Above this outlet a distance h is another pipe of diameter d? = 7.81 cm. This is
indicated in the picture here.
d?, P?
h
d?, P? d?, P?
We also know P? – P? = P?? = -5.69 kPa and P? – P? = P?? = -53.7 kPa.
a. (Q7 ans 2 pts, Q8 work 5 pts) What is the velocity of the fluid at point 3?
b. (Q9, 7 pts) What is the velocity of the fluid at point 2?
c. (Q10, 7 pts) What is the density of the fluid? (As a hint, you only need points 2 and 3 for this).
d. (Q11, 7 pts) What is the height difference between points 1 and 2, called h in this picture?
To continue, please give the fluid velocity at point 3 (part a) in units of m/s.

Added by Daniel R.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Supreeta N

10/25/2023

Step 1

The velocity of the fluid at point 3 can be calculated using the equation of continuity, which states that the product of the cross-sectional area (A) and the velocity (v) at any point along a pipe is constant. Show more…

Show all steps

lock

Thanks for your feedback!

Fluid coming out of a pipe has a volumetric flow rate of m = 7.3110-3 m3/s (I'm only using this variable name for convenience in your partial credit work).At the outlet, the diameter of the pipe is d3 = 1.00 cm.Further back from the outlet but at the same height is a different diameter pipe where d2 = 5.05 cm.Above this outlet a distance h is another pipe of diameter d = 7.81 cm.This is indicated in the picture here. d1,P1 d2,P2 d3,P We also know P-P=P31=-5.69 kPa and P-P=P3=-53.7 kPa a. (Q7 ans 2 pts,Q8 work 5 pts) What is the velocity of the fluid at point 3? b. (Q9, 7 pts) What is the velocity of the fluid at point 2? c. (Q10, 7 pts) What is the density of the fluid? (As a hint, you only need points 2 and 3 for this) d. (Q11, 7 pts) What is the height difference between points 1 and 2, called h in this picture? To continue, please give the fluid velocity at point 3 (part a) in units of m/s

Play audio

Feedback

Powered by NumerAI

Supreeta N and 63 other subject Physics 101 Mechanics educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Recommended Videos

Recommended Textbooks

Transcript

00:01 Hello students, for the a part diameter d3 is given as 1 cm.

00:10 So this will be equal to so radius r3 will be equal to d3 by 2 that will be equal to 5 into 10 raised to minus 3 meter and here the flow rate eta is given as 7 .31 into 10 raised to minus 3 meter cube per second, meter cube per second.

00:42 So according to equation of continuity, according to equation of continuity, according to equation of continuity flow rate eta should be constant at every points.

01:06 So flow rate should be constant.

01:11 So eta at point 3 at the pipe having diameter d3 will be equal to a3 into area into velocity, a3 is the area of the pipe that will be pi into 5 into 10 raised to minus 3 whole square into v3.

01:31 So v3 will be equal to eta divided by pi into 5 into 10 raised to minus 3 whole square.

01:41 So this will be equal to 7 .31 into 10 raised to minus 3 divided by pi into 5 into 10 raised to minus 3 whole square.

02:02 So if we calculate we will get velocity v3, this will be equal to 93 .12 meter per second.

02:11 So in the b part we have to find out the velocity for the pipe d2.

02:16 So diameter d2 is given as 5 .05 centimeter.

02:22 So radius r2 will be equal to 0 .0252 meter.

02:30 So flow rate eta will be equal to a2 into v2.

02:35 So velocity v2 will be equal to eta divided by area of cross section of pipe 2.

02:43 This will be equal to 7 .31 into 10 raised to minus 3 divided by pi into 0 .0252 whole square.

02:56 So if we calculate we will get the velocity v2 will be equal to 3 .66 meter per second.

03:08 So in the c part we have to find out the density rho.

03:15 So density rho density of the liquid will be equal to 1 by eta...
