QUESTION #3 Calculate the forces in members BD, CD and CE of the truss. State whether the member is in tension or compression. D B 4.5 kN + 4 m A C E 3 m 3 m 3m 13.5 kN QUESTION #4 Calculate the forces in members CD, CG and DG of the truss. State whether the member is in tension or compression. 1.5 m 6 kN 4 kN 6 kN 2 m 2 m 2 m 2 m B C D A E F G H 10 kN 5 kN 8 kN
