3. In the circuit shown in figure, the current flowing through 5 ? resistance is : 2 5 20 8 2.1A (A) 0.5A (B) 0.6A (C) 0.9 A (D) 1.5 A

          3. In the circuit shown in figure, the current flowing through 5 ? resistance is :
2
5
20
8
2.1A
(A) 0.5A (B) 0.6A (C) 0.9 A (D) 1.5 A

Added by Ann B.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Darshan Maheshwari

05/01/2022

Step 1

Given resistances: - 18 Ohm - 2 Ohm - 5 Ohm The resistances in series are: - 18 Ohm + 2 Ohm = 20 Ohm - 20 Ohm + 5 Ohm = 25 Ohm The total equivalent resistance is 25 Ohm. Show more…
