Problem statement: The Matlab file mdt 24 . mat contains $ N=1000 $ realizations of a random vector $ \mathbf{Y} $. Each realization (each vector $ \mathbf{y} $ ) has $ M=16 $ elements corresponding to multiple observations. Your task is to design the detector, and make $ N=1000 $ decisions, one for each realization $ \mathbf{y} $. A decision is either 1 , corresponding to "signal present," or 0 , corresponding to "signal absent." The detection problem is specified as follows: \[ \begin{array}{l} H_{0}: \mathbf{Y}=\mathbf{Z} \\ H_{1}: \mathbf{Y}=A \mathbf{s}+\mathbf{Z} \end{array} \] The noise is circularly symmetric complex Gaussian, $ \mathbf{Z} \sim \mathcal{C N}\left(\mathbf{0}, \sigma_{Z_{1}}^{2} \mathbf{I}\right) $. In other words, each element of $ \mathbf{Z} $ consists of independent zero-mean Gaussian real/imaginary parts of variance $ \sigma_{Z_{1}}^{2} / 2 $. The elements (different noise observations) are uncorrelated, as evident from the diagonal structure of the covariance matrix $ \mathbf{C}_{\mathbf{Z}}=E\left\{\mathbf{Z Z}^{\prime}\right\}=\sigma_{Z_{1}}^{2} \mathbf{I} $ (prime denotes conjugate transpose). The amplitude $ A $ is real-valued, positive and constant, and the vector $ \mathbf{s} $ is defined in terms of a phase $ \phi $ as \[ \mathbf{s}=\left[\begin{array}{c} 1 \\ e^{-j \phi} \\ e^{-j 2 \phi} \\ \vdots \\ e^{-j(M-1) \phi} \end{array}\right] \] This type of problem is found in radar/sonar, or any type of sounding or probing, when an array of $ M $ receivers is used to detect presence/absence of a signal. If the array receivers are separated by a distance $ d $, and the signal of wavelength $ \lambda $ arrives to the array from direction $ \theta $, the phase $ \phi $ is given by \[ \phi=2 \pi \frac{d}{\lambda} \sin \theta \] In the present problem, the direction of arrival is $ \theta=20^{\circ} $, and $ d=\frac{\lambda}{2} $. The variance of the noise is $ \sigma_{Z_{1}}^{2}=1 $. 1 Specific tasks: 1) Specify the relevant probability density functions $ f_{0}(\mathbf{y}) $ and $ f_{1}(\mathbf{y}) $. 2) State the likelihood ratio test (LRT). 3) Identify the sufficient statistic and set the decision threshold to ensure probability of false alarm of $ 10 \% $. 4) Apply the resulting Neuman-Pearson detection rule to the data stored in mdt 24 . mat. How many "signal present" decisions have you made?

          Problem statement: The Matlab file mdt 24 . mat contains \( N=1000 \) realizations of a random vector \( \mathbf{Y} \). Each realization (each vector \( \mathbf{y} \) ) has \( M=16 \) elements corresponding to multiple observations. Your task is to design the detector, and make \( N=1000 \) decisions, one for each realization \( \mathbf{y} \). A decision is either 1 , corresponding to "signal present," or 0 , corresponding to "signal absent."

The detection problem is specified as follows:
\[
\begin{array}{l}
H_{0}: \mathbf{Y}=\mathbf{Z} \\
H_{1}: \mathbf{Y}=A \mathbf{s}+\mathbf{Z}
\end{array}
\]

The noise is circularly symmetric complex Gaussian, \( \mathbf{Z} \sim \mathcal{C N}\left(\mathbf{0}, \sigma_{Z_{1}}^{2} \mathbf{I}\right) \). In other words, each element of \( \mathbf{Z} \) consists of independent zero-mean Gaussian real/imaginary parts of variance \( \sigma_{Z_{1}}^{2} / 2 \). The elements (different noise observations) are uncorrelated, as evident from the diagonal structure of the covariance matrix \( \mathbf{C}_{\mathbf{Z}}=E\left\{\mathbf{Z Z}^{\prime}\right\}=\sigma_{Z_{1}}^{2} \mathbf{I} \) (prime denotes conjugate transpose). The amplitude \( A \) is real-valued, positive and constant, and the vector \( \mathbf{s} \) is defined in terms of a phase \( \phi \) as
\[
\mathbf{s}=\left[\begin{array}{c}
1 \\
e^{-j \phi} \\
e^{-j 2 \phi} \\
\vdots \\
e^{-j(M-1) \phi}
\end{array}\right]
\]

This type of problem is found in radar/sonar, or any type of sounding or probing, when an array of \( M \) receivers is used to detect presence/absence of a signal. If the array receivers are separated by a distance \( d \), and the signal of wavelength \( \lambda \) arrives to the array from direction \( \theta \), the phase \( \phi \) is given by
\[
\phi=2 \pi \frac{d}{\lambda} \sin \theta
\]

In the present problem, the direction of arrival is \( \theta=20^{\circ} \), and \( d=\frac{\lambda}{2} \). The variance of the noise is \( \sigma_{Z_{1}}^{2}=1 \).
1
Specific tasks:
1) Specify the relevant probability density functions \( f_{0}(\mathbf{y}) \) and \( f_{1}(\mathbf{y}) \).
2) State the likelihood ratio test (LRT).
3) Identify the sufficient statistic and set the decision threshold to ensure probability of false alarm of \( 10 \% \).
4) Apply the resulting Neuman-Pearson detection rule to the data stored in mdt 24 . mat. How many "signal present" decisions have you made?
