Question

Q1) 1.28 gm of a powder of a particle density 2500 kg/m³ are charged into the cell of an apparatus for measurements of particle size and specific surface area by permeametry. The cylindrical cell has a dimeter of 1.14 cm and the powder forms a bed depth of (1 cm). Dry air of density 1.2 kg/m³ and viscosity of 18 * 10⁻⁶ Pa. s flows at a rate of 36 cm³/min through the powder (in a direction parallel to the axis of the cylindrical cell) and producing a pressure difference of 981 Pa across the bed. The system steady state and the particles are spherical in shape. Find the following: A) The surface-mean diameter (effective diameter Dₚ). B) Specific surface of the powder (m²/kg) C) The Reynolds number (N_{Re,p}) NOTE: use the following equation in the solution: Δp = (150μv' ΔL (1 – ε)²)/ (Dₚ² ε³)

          Q1) 1.28 gm of a powder of a particle density 2500 kg/m³ are charged into the cell of an apparatus
for measurements of particle size and specific surface area by permeametry. The cylindrical cell
has a dimeter of 1.14 cm and the powder forms a bed depth of (1 cm). Dry air of density 1.2 kg/m³
and viscosity of 18 * 10⁻⁶ Pa. s flows at a rate of 36 cm³/min through the powder (in a direction
parallel to the axis of the cylindrical cell) and producing a pressure difference of 981 Pa across the
bed. The system steady state and the particles are spherical in shape. Find the following:

A) The surface-mean diameter (effective diameter Dₚ).
B) Specific surface of the powder (m²/kg)
C) The Reynolds number (N_{Re,p})
NOTE: use the following equation in the solution:

Δp = (150μv' ΔL (1 – ε)²)/ (Dₚ² ε³)
