Q1) a- Determine the voltage $$v_o$$ using superposition for the circuit shown in Figure 1. 4 A 8 $$\Omega$$ 12 V 5 $$\Omega$$ $$v_o$$ 2 A 10 $$\Omega$$ Figure 1
