Q1. Numerical Aperture and Acceptance angle of an Optical Fiber. (a) A light-emitting diode (LED) shines on a cleaved facet of an optical fiber as shown in the Figure 1 below. The refractive indices of the core and cladding are n1 and n2 respectively and the refractive index of air is 1. Show that the relation between the numerical aperture (NA) and the acceptance angle of an optical fiber is given by NA = sin?a = ?(n1Ā² - n2Ā²) Fig. 1: Acceptance angle of an optical fiber. (b) Determine the numerical aperture and the acceptance angle of an optical fiber if the refractive index of the core is n1=1.46 and the cladding is stripped out (replaced with air n2 = 1). (c) How does this change, when a glass cladding of refractive index n2 = 1.40, is added?
Added by Adam R.
Close
Step 1
We know that the numerical aperture (NA) is defined as: NA = ā(nāĀ² - nāĀ²) where nā is the refractive index of the core and nā is the refractive index of the cladding. Show moreā¦
Show all steps
Your feedback will help us improve your experience
Madhur L and 101 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
1. A fiber optic cable consists of a core with n = 1.58 surrounded by cladding having an index of refraction n = 1.45. A light ray hits the end of the fiber at the air-core interface at an angle of incidence of 56 Ā°. a. Calculate the numerical aperture of the optical cable NA = b. Calculate the half of the full acceptance angle, Īømax for the optical fiber Īømax = c. If the ray will not be totally internally reflected, calculate by how many degrees the angle of incidence is too large. If the ray will be totally internally reflected, enter "0" in the answer field. Think of ways to increase the NA of the optical fiber.
Sri K.
Light traveling in air strikes the core area of a fiber at an angle ĢĢĢ = 34.5Ā°, where ĢĢĢ is the angle between the incoming ray and the surface of the fiber. Upon striking the fiber, part of the beam is reflected and part of it is refracted. The angle between the reflected and refracted beams is 90Ā°. Given that the refractive index of cladding is 1.44 and the core radius is 30 Ī¼m: (a) what is the refractive index of the core? (b) what are the numerical aperture and the maximum acceptance angle im of this fiber? (c) If the fiber is immersed in water (nw = 1.33), what is the new maximum acceptance angle?
Animesh R.
Refractive indices for a step index fiber are 1.52 for the core and 1.41 for the cladding. Determine: a. The critical angle, b. The numerical aperture, c. The maximum incidence angle Īøm (see fig 10.3 for a definition) for light that is totally internally reflected.
Urvashi A.
