Q.1 The circuit shown in the figure has been connected for a long time. Calculate the potential difference between points of the c and d ($$V_{cd}=V_c-V_d$$) a b 2.00 $$\Omega$$ 3.00 $$\mu$$F c d 10.0 V 80.0 $$\Omega$$ e f 3.00 $$\Omega$$ A) 1V B) 2V C) 3 V D) 4 V E) 5 V 4.00 V
Added by Antonio R.
Close
Step 1
The circuit has been connected for a long time, which means it is in a DC steady state. In a DC steady state, a capacitor acts as an open circuit, meaning no current flows through it. Show more…
Show all steps
