Q4) A Y-connected synchronous motor whose nameplate is shown in Figure Q4 has a per-unit synchronous reactance of 0.9? and a per-unit resistance of 0.02?. GENERAL ELECTRIC SYNCHRONOUS MOTOR RATED HP 21,000 RPM 1200 PF 1.0 VOLTS 6600 PHASE 3 FREQ 60 CODE B AMP 1404 FRAME 9398 TYPE TS EXCITATION-VOLTS 125 AMP 5.2 HP 21,000 CONT. 80 °C RISE STATOR RTD 105 °C RISE ROTOR BY RESISTANCE OUTLINE-816E357 CAUTION BEFORE INSTALLING INSTRUCTIONS GEK-42586 OR OPERATING READ CONN. DIAG. 34A150850 WHEN ORDERING RENEWAL PARTS, GIVE THIS MOTOR MODEL & SERIAL NO. MODEL 264×766 SER. NO. 8374051 NP 34A770169-001 SCHENECTADY N.Y. MADE IN U.S.A. Figure Q4 a) Calculate the rated input power of this motor. (4 marks) b) Calculate the magnitude of the armature voltage EA at rated conditions. (4 marks) c) Calculate the maximum reactive power that can be simultaneously supplied by the motor if the input power of this motor is 10 MW. (8 marks) d) Calculate the power consumed by the field circuit at the rated conditions. (2 marks) e) Calculate the efficiency of this motor at full-load conditions. (2 marks)
Added by Joshua A.
Close
Step 1
However, in this case, the power factor is 1.0 (unity), so the formula simplifies to Power = Voltage x Current x √3. Substituting the given values, we get Power = 6600V x 1404A x √3 = 16.05 MW. Show more…
Show all steps
Your feedback will help us improve your experience
Adi S and 95 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Q4. Fig. Q4 shows the equivalent circuit of a 4-pole, 50Hz, 3-phase induction motor. The motor is fed by an inverter at a frequency of 52Hz and supply voltage of 208V/phase. If the motor runs at a slip of 0.04, determine: (a) the motor speed; (b) the motor input current; (c) the motor output torque. The supply frequency and voltage to the inverter are updated to 48Hz and 192V/phase respectively. If the motor speed is kept unchanged at 50Hz, find: (d) the motor input current; (e) the motor output torque.
Madhur L.
C4, CO4, PO2 (Q1) A 480 V, 60 Hz, four-pole synchronous motor draws 50 A from the line at unity power factor and full load. Assuming that the motor is lossless, answer the following questions: (i) Calculate the output torque of this motor. Express the answer both in newton-meters and in pound-feet. (2 Marks) (ii) What must be done to change the power factor to 0.8 leading? Explain your answer using phasor diagrams. (2 Marks) (iii) Calculate the magnitude of the line current to be if the power factor is adjusted to 0.8 leading? (2 Marks) (Q2) An induction motor has 120 V, 6 hp, 4 poles, 50 Hz. Y-connected induction motor and obtain a full-load slip of 6 percent. Calculate: (i) Synchronous speed of the motor (1 Mark) (ii) Rotor speed of the motor at rated load (1 Mark) (iii) Rotor frequency at rated load (1 Mark) (iv) Shaft torque of the motor (1 Mark)
Adi S.
