Question

E 0.4m A y_b 1.4m y_d D B C 2.5KN 4KN 2.5KN 1.2m 2m 1.5m 1.2m

          E
0.4m
A
y_b 1.4m
y_d
D
B
C
2.5KN
4KN 2.5KN
1.2m 2m 1.5m 1.2m

E
0.4m
A
yb 1.4m
yd
D
B
C
2.5KN
4KN 2.5KN
1.2m 2m 1.5m 1.2m

Added by Susan A.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Kratika Bhadauria

Step 1

First, let's calculate the tension at point B. We know that Tcosθ = H, where H is the horizontal component of the tension. At point B, the slope is maximum, so θ = 0. Therefore, Tc = H = 1071.81 KN. Show more…

Show all steps

lock

Thanks for your feedback!

The cable supports the three loads. Determine the sags Yb and Yd of points B and D. Note that the tension in the cable is maximum where the slope is maximum, as TcosÎ¸=H. The maximum cable tension occurs at B and the minimum cable tension occurs at C, where dy/dx=Î¸=0 and Tc=H=1071.81KN. EK 0.4m YB yo 1.4m B C 2.5KN 4KN 2.5KN 1.2m| 2m 1.5m |1.2m
