Question 1
20 pts
A machine of mass 260 kg is mounted on the middle of a fixed-fixed beam, with a viscous damping
mechanism not shown. The steel beam ($E = 207$ GPa) has the following dimensions: $a = 0.05$m, $b = 0.2$
m and $L = 4$m. It has been observed that when a harmonic force of magnitude 1000N is applied, the
maximum steady-state response occurred at a frequency of 650 rpm. Determine the equivalent
damping constant, neglecting the mass of the beam.
$F(t) = F_0 \cos \omega t$
$I = \frac{a^3b}{12}$
9129 N s/m
7919 s/m
6807 Ns/m
7007 N s/m

Show Instructions
Question 1
20 pts
A machine of mass 260 kg is mounted on the middle of a fixed-fixed beam, with a viscous damping
mechanism not shown. The steel beam (E = 207 GPa) has the following dimensions: a = 0.05m, b = 0.2
m and L = 4m. It has been observed that when a harmonic force of magnitude 1000N is applied, the
maximum steady-state response occurred at a frequency of 650 rpm. Determine the equivalent
damping constant, neglecting the mass of the beam.
F(t) = F0 cosω t
I = (a^3b)/(12)
9129 N s/m
7919 s/m
6807 Ns/m
7007 N s/m

Added by Kendra D.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Madhur L

08/23/2023

Step 1

Given: Frequency = 650 rpm To convert from rpm to rad/s, we use the conversion factor: 1 rpm = (2π/60) rad/s So, the frequency in rad/s is: Frequency = 650 rpm * (2π/60) rad/s = 68.333 rad/s Show more…

Show all steps

Thanks for your feedback!

Question 1: A machine of mass 260 kg is mounted on the middle of a fixed-fixed beam, with a viscous damping mechanism not shown. The steel beam (E=207 GPa) has the following dimensions: a=0.05 m, b=0.2 m, and L=4 m. It has been observed that when a harmonic force of magnitude 1000 N is applied, the maximum steady-state response occurred at a frequency of 650 rpm. Determine the equivalent damping constant, neglecting the mass of the beam. F1 = Fcos(mm x ()) O9129 Ns/m O7919 s/m 6807 Ns/m O.7007 Ns/m
