Question 10 1 pts When the preset and clear inputs to a JK flip-flop are HIGH, which of the following statement is true? The Q output is immediately cleared The Q output is an ambiguous state The flip-flop is free to respond to its J, K, and clock inputs The Q output is immediately set to 1
Added by Som M.
Close
Step 1
The preset input sets the Q output to 1, while the clear input resets the Q output to 0. Show more…
Show all steps
