Consider a steam power plant operating on the simple ideal Rankine cycle. Steam enters the turbine at 5 MPa and 300°C and is condensed in the condenser at a pressure of 250 kPa. If the specific work required by the pump is 2 kJ/kg, determine the thermal efficiency of this cycle.
Added by Jessica B.
Close
Step 1
Step 1: Determine the specific enthalpy at the turbine inlet (h1) using steam tables at 5 MPa and 300°C. Show more…
Show all steps
Your feedback will help us improve your experience
Sri K and 55 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Consider a steam power plant operating on the ideal reheat Rankine cycle. Steam enters the high-pressure turbine at 15 MPa and 600 °C and is condensed in the condenser at a pressure of 10 kPa. If the moisture content of the steam at the exit of the low-pressure turbine is not to exceed 10.4 percent, determine: a) The pressure at which the steam should be reheated, and (4.0 MPa) b) The thermal efficiency of the cycle. (45%) Assume that the steam is reheated to the inlet temperature of the high-pressure turbine.
Adi S.
Consider an ideal steam regenerative Rankine cycle with two feedwater heaters, one closed and one open. Steam enters the turbine at 10 MPa and 550°C and exhausts to the condenser at 10 kPa. Steam is extracted from the turbine at 0.8 MPa for the closed feedwater heater and at 0.3 MPa for the open one. The feedwater is heated to the condensation temperature of the extracted steam in the closed feedwater heater. The extracted steam leaves the closed feedwater heater as saturated liquid, which is subsequently throttled in the open feedwater heater. Show the cycle on a T-s diagram with respect to saturation lines and determine: (a) the mass flow rate of steam through the boiler for a net power output of 250 MW, and (b) the thermal efficiency of the cycle. Turbine Boiler Closed FWH Open FWH Condenser
Krishna G.
A boiler delivers steam at $10 \mathrm{MPa}, 550^{\circ} \mathrm{C}$ to a twostage turbine as shown in Fig. 11.17 . After the first stage, $25 \%$ of the steam is extracted at 1.4 MPa for a process application and returned at $1 \mathrm{MPa}, 90^{\circ} \mathrm{C}$ to the feedwater line. The remainder of the steam continues through the low-pressure turbine stage, which exhausts to the condenser at $10 \mathrm{kPa}$. One pump brings the feedwater to $1 \mathrm{MPa}$, and a second pump brings it to $10 \mathrm{MPa}$. Assume the first and second stages in the steam turbine have isentropic efficiencies of $85 \%$ and $80 \%$, respectively, and that both pumps are ideal. If the process application requires $5 \mathrm{MW}$ of power, how much power can then be cogenerated by the turbine?
