          Question 3
0 / 0.5 pts
Make an optimistic estimate for the
same scenario like the problem in the
module, m3.3: bone fracture problems
During a soccer game, an opponent
kicked your shin and created a 0.01
mm defect (crack) in your tibia as seen
in Figure 1. You plan to run a marathon
(42.2 km) the next day. Should you be
worried that your tibia will fracture if
the maximum stress your tibia will
experience is 11 MPa?
m = 2.5
C = 2.5 \times 10^{-6} m(MN/m^{3/2})^{-2.5}
Tips:
1. Calculate the maximum stress
intensity factor your tibia will
experience.
2. Find the critical stress intensity
factor in one of the tables in the
module. Choose the value for an
optimistic estimate.
3. Determine what the critical crack
length would be for fast fracture to
occur.
Defect
15 mm
figure 1: Tibia defect for the fracture problem
([1], figure 9.18)
What is the difference between the critical crack lengths for the conservative
and optimistic estimates?
Answer with an accuracy of 0.001 m.
Recall that the solution for the conservative estimate was shown in class on
Wednesday, October 2, and is in the Chapter 6 zybook lab.
You do not need to show the work for calculating the conservative estimate,
but you do need to show the work for the optimistic estimate and then the
difference in critical crack lengths.
0.0164
