Question

Question 9 of 11 View Policies Show Attempt History Current Attempt in Progress Your answer is partially correct. In the figure, two blocks, of mass $m_1 = 289$ g and $m_2 = 411$ g, are connected by a massless cord that is wrapped around a uniform disk of mass $M = 464$ g and radius $R = 12.2$ cm. The disk can rotate without friction about a fixed horizontal axis through its center; the cord cannot slip on the disk. The system is released from rest. Find (a) the magnitude of the acceleration of the blocks, (b) the tension $T_1$ in the cord at the left and (c) the tension $T_2$ in the cord at the right. (a) Number 4.32 Units $m/s^2$ (b) Number 1.25 Units N (c) Number 2.25 Units N

          Question 9 of 11
View Policies
Show Attempt History
Current Attempt in Progress
Your answer is partially correct.
In the figure, two blocks, of mass $m_1 = 289$ g and $m_2 = 411$ g, are connected by a massless cord that is wrapped around a uniform disk of mass $M = 464$ g and radius $R = 12.2$ cm. The disk can rotate without friction about a fixed horizontal axis through its center; the cord cannot slip on the disk. The system is released from rest. Find (a) the magnitude of the acceleration of the blocks, (b) the tension $T_1$ in the cord at the left and (c) the tension $T_2$ in the cord at the right.
(a) Number
4.32
Units
$m/s^2$
(b) Number
1.25
Units
N
(c) Number
2.25
Units
N

question 9 of 11 view policies show attempt history current attempt in progress your answer is partially correct in the figure two blocks of mass m1 289 g and m2 411 g are connected by a m 60339
