Replace the force and couple moment system acting on the beam by an equivalent resultant force and couple moment at point O (Figure 1). Suppose that F1= 450 N, F2 = 180 N, and M = 200 N⋅m Part A Determine the magnitude of the resultant force. Express your answer to three significant figures and include the appropriate units. Part B Determine the angle between the resultant force and the x axis. Express your answer in degrees to three significant figures. Part C Determine the equivalent resultant couple moment about point O Express your answer to three significant figures and include the appropriate units. Assume the positive direction is counterclockwise.

          Replace the force and couple moment system acting on the beam by an equivalent resultant force and couple moment at point O
 (Figure 1). Suppose that F1= 450 N, F2 = 180 N, and M = 200 N⋅m

Part A
Determine the magnitude of the resultant force.
Express your answer to three significant figures and include the appropriate units.

Part B
Determine the angle between the resultant force and the x
 axis.
Express your answer in degrees to three significant figures.

Part C
Determine the equivalent resultant couple moment about point O
Express your answer to three significant figures and include the appropriate units. Assume the positive direction is counterclockwise.
