Replace the loading on the frame shown in (Figure 1) by
a single resultant force. Take
$F_1= 550 N$ and $F_2 = 300 N$.
Determine the magnitude of the resultant force.
Express your answer to three significant figures and include the appropriate units.
$F_R =$ Value Units
Specify where its line of action intersects member $CD$, measured from end $C$.
Express your answer to three significant figures and include the appropriate units.
$x =$ Value Units
Figure
F2
250 N
1m-2m
-3 m
2 m
400 N-m
60°
D
