Required information NOTE: This is a multi-part question. Once an answer is submitted, you will be unable to return to this part. Consider the given beam and loading. 4 kips/ft 5 ft 2 ft 2 ft 8 kips 8 kips Determine the maximum absolute values of the shear and bending moment. The maximum absolute value of the shear force is kips. The maximum absolute value of the bending moment is kip·ft.

          Required information
NOTE: This is a multi-part question. Once an answer is submitted, you will be unable to return to this part.
Consider the given beam and loading.
4 kips/ft
5 ft
2 ft
2 ft
8 kips
8 kips
Determine the maximum absolute values of the shear and bending moment.
The maximum absolute value of the shear force is kips.
The maximum absolute value of the bending moment is kip·ft.
