Required information Two steel tubes are shrink-fitted together where the nominal diameters are 34, 39, and 44 mm. Careful measurement before fitting determined the diametral interference between the tubes to be 0.062 mm. After the fit, the assembly is subjected to a torque of 900 N-m and a bending-moment of 675 N-m. Assume that there is no slipping between the cylinders, analyze the outer cylinder at the inner and outer radius. Given: $S_y$ = 415 MPa. What is the value of the contact pressure created between the two tubes? The contact pressure created between the two tubes is MPa.

          Required information
Two steel tubes are shrink-fitted together where the nominal diameters are 34, 39, and 44 mm. Careful measurement
before fitting determined the diametral interference between the tubes to be 0.062 mm. After the fit, the assembly is
subjected to a torque of 900 N-m and a bending-moment of 675 N-m. Assume that there is no slipping between the
cylinders, analyze the outer cylinder at the inner and outer radius. Given: $S_y$ = 415 MPa.
What is the value of the contact pressure created between the two tubes?
The contact pressure created between the two tubes is  MPa.
