Rotating Unbalance 5. A rotating machine of mass M = 100 kg is supported on four elastic mounts, each having a stiffness of k = 50,000 N/m and damping constant of c = 500 N-s/m. The machine is rotating at a speed of 6000 rpm and has an eccentric mass m = 0.005 kg located at a distance of e = 0.1 m from the axis of rotation. a. Determine the amplitude of vibration of the machine b. Determine the amplitude of the force transmitted to the base
Added by Ver-Nica R.
Close
Step 1
The machine rotates at 6000 rpm. To convert this to rad/s, use the formula: ω = (2π × rpm) / 60 ω = (2π × 6000) / 60 = 628.32 rad/s Show more…
Show all steps
