Sequential circuit constructed with one T flip-flop A, one D flip-flop B, and input X. When X=0, the state of the circuit remains the same. When X=1, the circuit goes through the transitions from 00 to 01 to 10 back to 00, repeat.
Draw the state transition diagram.
Construct the state table.
Draw the circuit.
