Suppose that current flowing through a laterally insulated rod generates heat at a constant rate; then Problem 19 yields the equation $$ \frac{\partial u}{\partial t}=k \frac{\partial^{2} u}{\partial x^{2}}+C $$ Assume the boundary conditions $u(0, t)=u(L, t)=0$ and $u(x, 0)=f(x) .$ (a) Find the steady-state temperature $u_{\mathrm{ss}}(x)$ determined by $$ 0=k \frac{d^{2} u_{\mathrm{ss}}}{d x^{2}}+C, \quad u_{\mathrm{ss}}(0)=u_{\mathrm{ss}}(L)=0 $$ (b) Show that the transient temperature $$ u_{\mathrm{tr}}(x, t)=u(x, t)-u_{\mathrm{ss}}(x) $$ satisfies the boundary value problem $$ \begin{aligned} \frac{\partial u_{\mathrm{tr}}}{\partial t} &=k \frac{\partial^{2} u_{\mathrm{tr}}}{\partial x^{2}} \\ u_{\mathrm{tr}}(0, t) &=u_{\mathrm{tr}}(L, t)=0 \\ u_{\mathrm{tr}}(x, 0) &=g(x)=f(x)-u_{\mathrm{ss}}(x) \end{aligned} $$ Hence conclude from the formulas in (34) and (35) that $$ u(x, t)=u_{\mathrm{ss}}(x)+\sum_{n=1}^{\infty} c_{n} \exp \left(-n^{2} \pi^{2} k t / L^{2}\right) \sin \frac{n \pi x}{L} $$ where $$ c_{n}=\frac{2}{L} \int_{0}^{L}\left[f(x)-u_{\mathrm{ss}}(x)\right] \sin \frac{n \pi x}{L} d x . $$

          Suppose that current flowing through a laterally insulated rod generates heat at a constant rate; then Problem 19 yields the equation
$$
\frac{\partial u}{\partial t}=k \frac{\partial^{2} u}{\partial x^{2}}+C
$$
Assume the boundary conditions $u(0, t)=u(L, t)=0$ and $u(x, 0)=f(x) .$ (a) Find the steady-state temperature $u_{\mathrm{ss}}(x)$ determined by
$$
0=k \frac{d^{2} u_{\mathrm{ss}}}{d x^{2}}+C, \quad u_{\mathrm{ss}}(0)=u_{\mathrm{ss}}(L)=0
$$
(b) Show that the transient temperature
$$
u_{\mathrm{tr}}(x, t)=u(x, t)-u_{\mathrm{ss}}(x)
$$
satisfies the boundary value problem
$$
\begin{aligned}
\frac{\partial u_{\mathrm{tr}}}{\partial t} &=k \frac{\partial^{2} u_{\mathrm{tr}}}{\partial x^{2}} \\
u_{\mathrm{tr}}(0, t) &=u_{\mathrm{tr}}(L, t)=0 \\
u_{\mathrm{tr}}(x, 0) &=g(x)=f(x)-u_{\mathrm{ss}}(x)
\end{aligned}
$$
Hence conclude from the formulas in (34) and (35) that
$$
u(x, t)=u_{\mathrm{ss}}(x)+\sum_{n=1}^{\infty} c_{n} \exp \left(-n^{2} \pi^{2} k t / L^{2}\right) \sin \frac{n \pi x}{L}
$$
where
$$
c_{n}=\frac{2}{L} \int_{0}^{L}\left[f(x)-u_{\mathrm{ss}}(x)\right] \sin \frac{n \pi x}{L} d x .
$$

Show more…

Added by Vanessa S.

Differential Equations and Linear Algebra

Stephen W. Goode, Scott A. Annin 4th Edition

Instant Answer

Solved by Expert Shu-Ting Huang

01/06/2022

Step 1

The general solution is $$ u_{ss}(x) = Ax^2 + Bx + D $$ where A, B, and D are constants. The boundary conditions $u_{ss}(0)=u_{ss}(L)=0$ give us $$ D = 0, \quad AL^2 + BL = 0 $$ which implies that $A = -B/L$. Substituting this into the differential equation Show more…

Show all steps

lock

Thanks for your feedback!

Suppose that current flowing through a laterally insulated rod generates heat at a constant rate; then Problem 19 yields the equation $$ \frac{\partial u}{\partial t}=k \frac{\partial^{2} u}{\partial x^{2}}+C $$ Assume the boundary conditions $u(0, t)=u(L, t)=0$ and $u(x, 0)=f(x) .$ (a) Find the steady-state temperature $u_{\mathrm{ss}}(x)$ determined by $$ 0=k \frac{d^{2} u_{\mathrm{ss}}}{d x^{2}}+C, \quad u_{\mathrm{ss}}(0)=u_{\mathrm{ss}}(L)=0 $$ (b) Show that the transient temperature $$ u_{\mathrm{tr}}(x, t)=u(x, t)-u_{\mathrm{ss}}(x) $$ satisfies the boundary value problem $$ \begin{aligned} \frac{\partial u_{\mathrm{tr}}}{\partial t} &=k \frac{\partial^{2} u_{\mathrm{tr}}}{\partial x^{2}} \\ u_{\mathrm{tr}}(0, t) &=u_{\mathrm{tr}}(L, t)=0 \\ u_{\mathrm{tr}}(x, 0) &=g(x)=f(x)-u_{\mathrm{ss}}(x) \end{aligned} $$ Hence conclude from the formulas in (34) and (35) that $$ u(x, t)=u_{\mathrm{ss}}(x)+\sum_{n=1}^{\infty} c_{n} \exp \left(-n^{2} \pi^{2} k t / L^{2}\right) \sin \frac{n \pi x}{L} $$ where $$ c_{n}=\frac{2}{L} \int_{0}^{L}\left[f(x)-u_{\mathrm{ss}}(x)\right] \sin \frac{n \pi x}{L} d x . $$

Play audio

Feedback

Powered by NumerAI

Shu-Ting Huang and 54 other subject Differential Equations educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Recommended Videos

Recommended Textbooks

Transcript

00:01 In this question we are considering the partial differential equation d u over d t equal k d squared u over d x squared plus c with boundary condition u of 0 t u of l t both 0 and initial condition is u of x 0 equal f of x in part a, we are considering the steady -state solution that does not depend on t.

00:51 So we are going to find this u .s.

00:55 As such that 0 equal k -u -s -s double prime of x plus c with the boundary.

01:18 Condition us s of 0, uss of l both of 0.

01:30 We note that this is the same as u .s .s.

01:34 Double prime equal negative c over k.

01:43 Since the second derivative is a constant, and we know that this has two root.

01:54 So it is a second derivative is a constant we can write it as a degree two polynomial.

02:06 And we also know the two roots.

02:08 So it is xx minus l.

02:12 And this coefficient is negative c over 2k.

02:22 Now we come to part b.

02:23 In part b, we consider the chenuan solution, so this is u -tr -x -t equal u of xt minus the steady -state solution uss of x.

02:51 Then if we differentiate it with respect to t, we will get it is a steady -state solution, uss of x.

03:07 U over d t because this does not depend on t so it is now we go to the original equation k d square u over d x square plus c and this u can be written as ut plus u s so it is k d square utr dx square plus k d square u s over dx square plus k d square u s over dx square plus c and we know that this is the first time we just copy it and then the second and third term, because kus as double prime plus c is 0, so it's 0 here...
