The below sequential circuit is built using JK flip-flops. It is initialized with the initial values of A=1, B=0, and external input x is set to 0. What are the next state values of A and B for this circuit for the next clock cycle?
Clk
KA
TB Clk
Clock
Select one:
A(t+1)=1, B(t+1)=0
A(t+1)=x, B(t+1)=0
A(t+1)=1, B(t+1)=1
A(t+1)=0, B(t+1)=1
A(t+1)=0, B(t+1)=0
A(t+1)=1, B(t+1)=x
