The curved beam is subjected to a bending moment of as shown. Determine the maximum compressive and tensile stresses in the section. Take M = 900 N.m, $r_i$ = 400 mm, a = 100 mm, b = 120 mm, c = 15 mm, and d = 20 mm.
