The following data relate to a single-stage impulse turbine: Steam velocity = 600 m/s Blade speed = 250 m/s Nozzle angle = 20° Blade outlet angle = 25° Neglecting the effect of friction, calculate: - The power developed by the turbine for the steam flow rate of 20 kg/s. - The axial thrust on the bearing of the turbine rotor. - The blade efficiency.
