The following layout is for a manufacturing facility that has five departments (A, B, C, D, and E). A layout has been developed in discrete representation as shown below. The routing information, production quantity, and movement factor for each product are given in the table below.
1) Develop a from-to chart.
2) List all department pairs that CRAFT and Multiple would consider for exchanging in the layout below.
3) Draw three possible layouts resulting from exchanging departments A and C by CRAFT.
A
A
B
B
B
B
A
A
C
C
C
C
A
A
C
C
C
C
D
D
D
D
E
E
D
D
D
D
E
E
Product Processing Sequence Weekly Production Movement Factor
1 DAEBC 400 units 1
2 ADAC 200 units 9
3 BAEABE 600 units 2
4 BAED 500 units 1
