Question

The generator parameters are: S = 150 MVA, P = 130 MW, V = 11.5kV and Xs = 1.3 p.u. on rating, E = 2.2 p.u. (max). If the generator operates at 100 MW, calculate the value of internal voltage at which the generator delivers no reactive power to the system.
