Question

supported by a pin at J and a roller at G. Determine the force in member FH, FG, EG(make sure that you state whether the member is in tension or compression). 2000 N 2000 N 2000 N 2000 N 2000 N 2000 N 0.8 m 0.8 m 0.8 m 0.8 m 0.8 m A B D F H J 2.5 m C E G

          supported by a pin at J and a roller at G.
Determine the force in member FH, FG, EG(make
sure that you state whether the member is in
tension or compression).
2000 N  2000 N  2000 N  2000 N  2000 N  2000 N
0.8 m  0.8 m  0.8 m  0.8 m  0.8 m
A      B      D      F      H      J
2.5 m
C
E
G

supported by a pin at J and a roller at G.
Determine the force in member FH, FG, EG(make
sure that you state whether the member is in
tension or compression).
2000 N 2000 N 2000 N 2000 N 2000 N 2000 N
0.8 m 0.8 m 0.8 m 0.8 m 0.8 m
A B D F H J
2.5 m
C
E
G

Added by Jose Carlos V.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Umar Sohail Qureshi

Step 1

We have a vertical load of 2000 N at point H, and two vertical reactions at points G and J. Since the truss is in equilibrium, the sum of the vertical forces must be zero. Therefore, the reaction at point G must be equal to the sum of the vertical loads at points Show more…

Show all steps

Thanks for your feedback!

The Pratt truss is loaded as shown below and supported by a pin at J and a roller at G. Determine the force in members FH, FG, and EG (make sure to state whether the member is in tension or compression). 2000 N 2000 N 2000 N 2000 N 2000 N 0.8 m 0.8 m 0.8 m 0.8 m 0.8 m 2.5 m
