Part A The rod has a diameter of 40 mm. It is subjected to the force system $P_1 = 1100 \text{ N}$, $F_2 = 500 \text{ N}$, $F_3 = 900 \text{ N}$. (Figure 1) Determine the normal stress that acts at point A. Express your answer to three significant figures and include the appropriate units. Enter negative value in the case of compression and positive value in the case of tension. $\sigma_A = $ Value Units Submit Request Answer Part B Determine the shear stress $(\tau_{xy})$ that acts at point A. Express your answer to three significant figures and include the appropriate units. $(\tau_{xy}) = $ Value Units Submit Request Answer Part C Determine the shear stress $(\tau_{xz})$ that acts at point A. Express your answer to three significant figures and include the appropriate units. $(\tau_{xz}) = $ Value Units Submit Request Answer < Return to Assignment Provide Feedback
